FEC Encoders Tutorial

This tutorial demonstrates how to use various Forward Error Correction (FEC) encoders from the kaira.models.fec.encoders module.

FEC codes add redundancy to transmitted data, allowing receivers to detect and correct errors without retransmission.

We’ll explore:

• Basic block codes (Repetition, Single Parity Check)

• Linear block codes (Hamming)

• Cyclic codes and BCH codes

• Reed-Solomon codes

• Advanced features and performance evaluation

First, let’s import the necessary modules

import numpy as np
import torch

# Import encoders from kaira
from kaira.models.fec.encoders import (
    BCHCodeEncoder,
    CyclicCodeEncoder,
    GolayCodeEncoder,
    HammingCodeEncoder,
    LinearBlockCodeEncoder,
    ReedSolomonCodeEncoder,
    RepetitionCodeEncoder,
    SingleParityCheckCodeEncoder,
    SystematicLinearBlockCodeEncoder,
)
from kaira.utils.plotting import PlottingUtils

# Set random seed for reproducibility
torch.manual_seed(42)
np.random.seed(42)

# Configure plotting style
PlottingUtils.setup_plotting_style()

Helper Functions

Let’s define some helper functions to display code parameters and visualize codewords.

def print_code_parameters(encoder, name: str) -> None:
    """Print the parameters of a code encoder."""
    print(f"\n{name}:")
    print(f"  - Code length (n): {encoder.code_length}")
    print(f"  - Message length (k): {encoder.code_dimension}")
    print(f"  - Rate (k/n): {encoder.code_dimension/encoder.code_length:.3f}")
    if hasattr(encoder, "error_correction_capability"):
        print(f"  - Error correction capability (t): {encoder.error_correction_capability}")
    if hasattr(encoder, "generator_matrix"):
        print("  - Has generator matrix: Yes")
    if hasattr(encoder, "parity_check_matrix"):
        print("  - Has parity check matrix: Yes")


def visualize_codeword(message: torch.Tensor, codeword: torch.Tensor, name: str) -> None:
    """Visualize a message and its corresponding codeword."""
    # Create simple visualization by creating mock generator and parity check matrices
    # Based on common Hamming code structure
    if len(message) == 4 and len(codeword) == 7:  # Hamming(7,4)
        generator_matrix = torch.tensor([[1, 0, 0, 0, 1, 1, 0], [0, 1, 0, 0, 1, 0, 1], [0, 0, 1, 0, 0, 1, 1], [0, 0, 0, 1, 1, 1, 1]], dtype=torch.float32)

        parity_check_matrix = torch.tensor([[1, 1, 0, 1, 1, 0, 0], [1, 0, 1, 1, 0, 1, 0], [0, 1, 1, 1, 0, 0, 1]], dtype=torch.float32)
    else:
        # Create generic matrices for other codes
        k, n = len(message), len(codeword)
        generator_matrix = torch.cat([torch.eye(k), torch.randint(0, 2, (k, n - k))], dim=1).float()
        parity_check_matrix = torch.cat([torch.randint(0, 2, (n - k, k)), torch.eye(n - k)], dim=1).float()

    PlottingUtils.plot_hamming_code_visualization(generator_matrix, parity_check_matrix, f"{name} Code Structure")

Part 1: Basic Block Codes

Let’s start with the simplest FEC codes: repetition codes and single parity check codes.

Repetition Code

A repetition code simply repeats each bit of the message multiple times. For a 3x repetition code, each message bit is encoded as 3 identical bits.

rep_encoder = RepetitionCodeEncoder(repetitions=3)
print_code_parameters(rep_encoder, "Repetition Code (3x)")

# Create a simple message
message = torch.tensor([1.0, 0.0, 1.0, 1.0, 0.0])
# Original message: [1, 0, 1, 1, 0]

# Encode using repetition code
codeword = rep_encoder(message)
# Encoded codeword: [1, 1, 1, 0, 0, 0, 1, 1, 1, 1, 1, 1, 0, 0, 0]

# Visualize the encoding
visualize_codeword(message, codeword, "Repetition Code (3x)")

Repetition Code (3x):
  - Code length (n): 3
  - Message length (k): 1
  - Rate (k/n): 0.333
  - Has generator matrix: Yes
  - Has parity check matrix: Yes

Single Parity Check Code

A single parity check code adds one parity bit to the message to ensure the total number of 1s in the codeword is even (even parity).

spc_encoder = SingleParityCheckCodeEncoder(dimension=4)
print_code_parameters(spc_encoder, "Single Parity Check Code")

# Encode using single parity check code
message = torch.tensor([1.0, 1.0, 0.0, 1.0])
codeword = spc_encoder(message)
# Original message: [1, 1, 0, 1]
# Encoded codeword: [1, 1, 0, 1, 1]
# Parity bit: 1 (to make even parity)

Single Parity Check Code:
  - Code length (n): 5
  - Message length (k): 4
  - Rate (k/n): 0.800
  - Has generator matrix: Yes
  - Has parity check matrix: Yes

Part 2: Linear Block Codes

Linear block codes are more sophisticated and offer better error correction capabilities while maintaining good code rates.

Hamming Code

Hamming codes are perfect codes that can correct one error. The Hamming(7,4) code encodes 4 message bits into 7 code bits.

hamming_encoder = HammingCodeEncoder(mu=3)  # Hamming(7,4) code
print_code_parameters(hamming_encoder, "Hamming(7,4) Code")

# Create a message
message = torch.tensor([1.0, 0.0, 1.0, 1.0])
# Original message: [1, 0, 1, 1]

# Encode using Hamming code
codeword = hamming_encoder(message)
# Encoded codeword: [1, 0, 1, 1, 1, 0, 1]

# Display the generator matrix
# Generator Matrix G:
# [[1 0 0 0 1 1 0]
#  [0 1 0 0 1 0 1]
#  [0 0 1 0 0 1 1]
#  [0 0 0 1 1 1 1]]

Hamming(7,4) Code:
  - Code length (n): 7
  - Message length (k): 4
  - Rate (k/n): 0.571
  - Has generator matrix: Yes
  - Has parity check matrix: Yes

Custom Linear Block Code

We can create custom linear block codes by defining our own generator matrix.

# Define a custom generator matrix for a (6,3) linear block code
G = torch.tensor([[1.0, 0.0, 0.0, 1.0, 1.0, 0.0], [0.0, 1.0, 0.0, 0.0, 1.0, 1.0], [0.0, 0.0, 1.0, 1.0, 0.0, 1.0]])

custom_encoder = LinearBlockCodeEncoder(generator_matrix=G)
print_code_parameters(custom_encoder, "Custom (6,3) Linear Block Code")

message = torch.tensor([1.0, 1.0, 0.0])
codeword = custom_encoder(message)
# Original message: [1, 1, 0]
# Encoded codeword: [1, 1, 0, 1, 0, 1]

Custom (6,3) Linear Block Code:
  - Code length (n): 6
  - Message length (k): 3
  - Rate (k/n): 0.500
  - Has generator matrix: Yes
  - Has parity check matrix: Yes

Part 3: Cyclic Codes and BCH Codes

Cyclic codes have the property that any cyclic shift of a codeword is also a codeword. BCH codes are a class of cyclic codes with excellent error correction capabilities.

Cyclic Code

Let’s use a standard Hamming(7,4) code, which is a cyclic code.

cyclic_encoder = CyclicCodeEncoder.create_standard_code("Hamming(7,4)")
print_code_parameters(cyclic_encoder, "Cyclic Code (7,4)")

message = torch.tensor([1.0, 0.0, 1.0, 1.0])
codeword = cyclic_encoder(message)
print(f"Original message: {message.int().tolist()}")
print(f"Encoded codeword: {codeword.int().tolist()}")

Cyclic Code (7,4):
  - Code length (n): 7
  - Message length (k): 4
  - Rate (k/n): 0.571
  - Has generator matrix: Yes
  - Has parity check matrix: Yes
Original message: [1, 0, 1, 1]
Encoded codeword: [1, 0, 1, 1, 0, 1, 1]

BCH Code

BCH codes are powerful cyclic codes that can correct multiple errors. Here we create a BCH(15,7) code that can correct up to 2 errors.

bch_encoder = BCHCodeEncoder(mu=4, delta=5)  # GF(2^4), minimum distance 5
print_code_parameters(bch_encoder, "BCH(15,7) Code")

message = torch.tensor([1.0, 0.0, 1.0, 1.0, 0.0, 1.0, 0.0])
codeword = bch_encoder(message)
print(f"Original message: {message.int().tolist()}")
print(f"Encoded codeword: {codeword.int().tolist()}")

BCH(15,7) Code:
  - Code length (n): 15
  - Message length (k): 7
  - Rate (k/n): 0.467
  - Error correction capability (t): 2
  - Has generator matrix: Yes
  - Has parity check matrix: Yes
Original message: [1, 0, 1, 1, 0, 1, 0]
Encoded codeword: [1, 0, 1, 1, 0, 1, 0, 0, 1, 0, 1, 1, 0, 1, 0]

Golay Code

The binary Golay code is a perfect code that can correct up to 3 errors.

golay_encoder = GolayCodeEncoder()
print_code_parameters(golay_encoder, "Binary Golay(23,12) Code")

message = torch.tensor([1.0, 0.0, 1.0, 1.0, 0.0, 1.0, 0.0, 1.0, 1.0, 0.0, 0.0, 1.0])
codeword = golay_encoder(message)
print(f"Original message: {message.int().tolist()}")
print(f"Encoded codeword: {codeword.int().tolist()}")

Binary Golay(23,12) Code:
  - Code length (n): 23
  - Message length (k): 12
  - Rate (k/n): 0.522
  - Error correction capability (t): 3
  - Has generator matrix: Yes
  - Has parity check matrix: Yes
Original message: [1, 0, 1, 1, 0, 1, 0, 1, 1, 0, 0, 1]
Encoded codeword: [1, 0, 1, 1, 0, 1, 0, 1, 1, 0, 0, 1, 0, 0, 1, 0, 1, 1, 0, 0, 1, 1, 0]

Part 4: Reed-Solomon Codes

Reed-Solomon codes are particularly good at correcting burst errors.

Reed-Solomon Code

Reed-Solomon codes operate on symbols rather than bits, making them excellent for burst error correction.

# RS(15,9) code over GF(2^4)
# - mu=4 since the code length is n=2^mu-1=15
# - The redundancy is r=n-k=15-9=6
# - The design distance is delta=r+1=7
rs_encoder = ReedSolomonCodeEncoder(mu=4, delta=7)
print_code_parameters(rs_encoder, "Reed-Solomon(15,9) Code")

# Create a message for RS encoding
message = torch.tensor([1.0, 1.0, 0.0, 1.0, 0.0, 0.0, 1.0, 1.0, 0.0])  # 9 symbols
codeword = rs_encoder(message)
print(f"Original message: {message.int().tolist()}")
print(f"Encoded codeword: {codeword.int().tolist()}")
print(f"RS can correct up to {rs_encoder.error_correction_capability} symbol errors")

Reed-Solomon(15,9) Code:
  - Code length (n): 15
  - Message length (k): 9
  - Rate (k/n): 0.600
  - Error correction capability (t): 3
  - Has generator matrix: Yes
  - Has parity check matrix: Yes
Original message: [1, 1, 0, 1, 0, 0, 1, 1, 0]
Encoded codeword: [1, 1, 0, 1, 0, 0, 1, 1, 0, 1, 1, 1, 1, 1, 1]
RS can correct up to 3 symbol errors

Part 5: Advanced Features

Now let’s explore some advanced features of FEC codes.

Systematic Encoding

A systematic code preserves the original message bits in the codeword, making it easier to extract the message without full decoding.

# Create a systematic linear block code from a parity submatrix
# For a systematic code, we need the parity submatrix P rather than the full generator matrix
# For our (6,3) code, the first 3 columns are identity and remaining 3 are parity
G = torch.tensor([[1.0, 0.0, 0.0, 1.0, 1.0, 0.0], [0.0, 1.0, 0.0, 0.0, 1.0, 1.1], [0.0, 0.0, 1.0, 1.0, 0.0, 1.0]])

# Extract the parity submatrix (last 3 columns)
P = G[:, 3:]

# Initialize the systematic encoder with the parity submatrix
systematic_encoder = SystematicLinearBlockCodeEncoder(parity_submatrix=P)
print_code_parameters(systematic_encoder, "Systematic (6,3) Linear Block Code")

message = torch.tensor([1.0, 1.0, 0.0])
codeword = systematic_encoder(message)
print(f"Original message: {message.int().tolist()}")
print(f"Encoded codeword: {codeword.int().tolist()}")
print("Note how the first 3 bits of the codeword match the message (systematic property)")

Systematic (6,3) Linear Block Code:
  - Code length (n): 6
  - Message length (k): 3
  - Rate (k/n): 0.500
  - Has generator matrix: Yes
  - Has parity check matrix: Yes
Original message: [1, 1, 0]
Encoded codeword: [1, 1, 0, 1, 0, 1]
Note how the first 3 bits of the codeword match the message (systematic property)

Batch Processing

All encoders support batch processing to encode multiple messages at once.

# Encode multiple messages at once using batch dimensions
messages = torch.tensor([[1.0, 0.0, 1.0, 1.1], [0.0, 1.0, 1.0, 0.0], [1.0, 1.0, 0.0, 0.0]])  # First message  # Second message  # Third message

# Encode all messages at once with the Hamming encoder
codewords = hamming_encoder(messages)
print(f"Batch of messages shape: {messages.shape}")
print(f"Batch of codewords shape: {codewords.shape}")

for i in range(len(messages)):
    print(f"Message {i+1}: {messages[i].int().tolist()} → Codeword: {codewords[i].int().tolist()}")

Batch of messages shape: torch.Size([3, 4])
Batch of codewords shape: torch.Size([3, 7])
Message 1: [1, 0, 1, 1] → Codeword: [1, 0, 1, 1, 0, 1, 0]
Message 2: [0, 1, 1, 0] → Codeword: [0, 1, 1, 0, 1, 1, 0]
Message 3: [1, 1, 0, 0] → Codeword: [1, 1, 0, 0, 0, 1, 1]

Part 6: Performance Evaluation

Finally, let’s compare the performance characteristics of different codes.

Comparing Code Rates

The code rate (k/n) represents the efficiency of the code. Higher rates mean less redundancy but typically weaker error correction.

encoders = {
    "Repetition (3x)": RepetitionCodeEncoder(repetition_factor=3),
    "Single Parity Check": SingleParityCheckCodeEncoder(dimension=4),
    "Hamming(7,4)": HammingCodeEncoder(mu=3),
    "BCH(15,7)": BCHCodeEncoder(mu=4, delta=5),
    "RS(15,9)": ReedSolomonCodeEncoder(mu=4, delta=7),
    "Golay(23,12)": GolayCodeEncoder(),
}

# Compute and plot code rates
names = []
rates = []
min_distances = []

for name, encoder in encoders.items():
    rate = encoder.code_dimension / encoder.code_length
    rates.append(rate)
    names.append(name)

    # Get minimum distance if available
    if hasattr(encoder, "minimum_distance"):
        min_dist = encoder.minimum_distance
        if callable(min_dist):
            min_dist = min_dist()
        min_distances.append(min_dist)
    elif hasattr(encoder, "design_distance"):
        min_dist = encoder.design_distance
        if callable(min_dist):
            min_dist = min_dist()
        min_distances.append(min_dist)
    else:
        min_distances.append(None)

# Generate code comparison visualization
metrics = {"Code Rate": rates, "Min Distance": [d if d is not None else 0 for d in min_distances]}
PlottingUtils.plot_complexity_comparison(names, metrics, "Comparison of FEC Code Performance")

# Code Rates and Minimum Distances Summary:
print("\nCode Rates and Minimum Distances:")
for i, name in enumerate(names):
    print(f"{name}: Rate = {rates[i]:.3f}, Min Distance = {min_distances[i]}")

Code Rates and Minimum Distances:
Repetition (3x): Rate = 0.333, Min Distance = None
Single Parity Check: Rate = 0.800, Min Distance = 2
Hamming(7,4): Rate = 0.571, Min Distance = 3
BCH(15,7): Rate = 0.467, Min Distance = 5
RS(15,9): Rate = 0.600, Min Distance = None
Golay(23,12): Rate = 0.522, Min Distance = 7

Conclusion

This tutorial demonstrated various FEC encoders from the kaira library.

The choice of encoder depends on the specific requirements of the application:

• Repetition codes are simple but inefficient

• Hamming codes are efficient for single-error correction

• BCH and Reed-Solomon codes provide strong error correction for burst errors

• Systematic codes preserve the original message in the codeword

For error correction, pair these encoders with their corresponding decoders.
